Qianhe is a professional manufacturer for coil winding tensioner, We offer Magnetic tensioner and servo tensioner

for coil winding machine with best quality and the most competitive price in china.

Tensioner is a necessary factor for keeping consistent winding accuracy.
Selecting better tensioner provides a sophisticated winding machine with best performance.

Stabilized tensioner improves winding problems and enhances productivity.

For example, stabilized tensioner causes no breaking of wire, raises operation rate,

secures the value of resistance, and increases credibility of the product.

Perfect layer winding leads to material cost cutting and easy adjustment.

Therefore, time and cost for machine maintenance can be decreased.

Key advantages of Magnetic wire tensioners:

These magnetic tensioners use a device containing a permanent magnet as a

non-contact method of generating a variable resistance to rotation of the main

wheel of the tensioner, thus maintaining wire tension at the set value for longer

periods than their mechanical counterparts with greatly reduced requirement for

adjustment.

• Polished ceramic eyelets and guide rollers at each point of contact protect the insulating enamel from mechanical damage.
• The performance of these magnetic wire tensioners is exceptional given the low cost,
• providing outstanding value for money.
• Captive roller on tension arm is easy to thread, eliminates chance of losing wire.

Specification :

Hanging line diagram

Tensioner test conditions :

Wire speed is 10M/S, instant start, stop the continuous line, stable tension in the positive

and negative 1%g.

Key features of Type MTC300S :

• Tension Scope :14-4000g
• Applied wire diameter : 0.06-0.30
• Tension Rod : CX-4#

Picture show:

Coil Winding Machine Tensioner

Hangzhou Qianhe Precision Machinery Co., Ltd. was established in 2006, It is a national High-tech enterprise which specializing in the design and production of all kinds of automatic winding machine accessories. There three core advantages: 1. Servo tensioner and tension measurement ; 2.Air Nipper and winding fixture ; 3.Hard Alloy Winding Nozzle / guide needle .

For more than ten years, we hold the tenet of “integrity, pragmatism, innovation, and do global customer satisfaction”, and applies advanced quality management standards to the whole process of product realization, striving to create “high-hard and high- fine and more Excellent products.The three series of products have been widely used in the advanced automatic CNC winding equipment at home and abroad, and won the praise of the market and customers.

We are a national high- tech company ,with a mature R&D and management team ( obtained a number of patent certificates).with a group of skilled production technology backbone.the main management staff have more than 16 years of work experience in this field .We regard "Conscience, Ingenuity and Innovation" as the core of corporate culture, and promise to provide our customers with the most sincere, professional and quality services.

Mr. Zhang,General Manager

We have employees more than 100 and 3,000 square meters plants.The main management staff engaged in this field more than 10 years.we design and developed with four series products.

We produce all kinds of winding machine spare parts ,the main products are winding tensiner ,winding nozzle ,Air Nipper ,wire stripper ,tension meter and Ceramic pulleys.

Our winding tensioner working in different brand of winding machine and using in different fields.

We are a national high-paying technology company and have obtained a number of patent certificates.
