Wear Resistant Stainless Steel Nozzle In CNC Automatic Winding Machine

Detailed Product Description:

Ruby Nozzle is made of two main parts, stainless steel and the processed ruby.

It has been widely used in CNC automatic winding machine.

The Ruby Material has the characteristics of extremely hard and wear-resistant

by precise processing

and combination. The rigidity of ruby is above than level 9 and is just less than

that of diamond. Ruby nozzle guide is a single crystal and can be made with high

brightness and cleanness. It can effectively protect paint film and ling term continual work.

Ruby Nozzles also call wire guide tubes,wire guide eyelets,wire guide needles.

It is used on coil winding machines and cable machines for wire guide.

Key advantages of Ruby Tipped Coil Winding Nozzle:

1) High Wear Resistance
This is assured by the choice of materials for wear elements possessing. Hardness Value

1800 ~ 2200Vickers, or 3times that of case hardened steel. Body material is stainless

steel for structural supports, not wear-bearing.

2) Scratch-Proofing
Eliminate wire insulation film damage, low friction resistance, stable wire tension. The

wire-guiding surfaces are mirror finished by diamond lapping to a surface roughness of

2 -4 micro inches Ra or better, material permit.

3) Straightness and Stiffness
Straightness and Stiffness are defined by the wire exit being concentric and inflexible

with respect to the nozzle locating? . In plain terms, the wire should exit from the nozzle

concentric to the locating? To within 0.02 mm, with or without load. A geometric

characteristic presentation is shown at upper left. Concentricity to within 0.01mm.

4) Precise Exit Radii
Because the coil winding nozzle's Exit Radii governs the angle of the wire exit from one

coil to the next, it should be monitored to + / - 0.025 mm. This is done by digital

measurement, shown at upper right.

Specification and description:

Ruby Nozzle Drawings

Size List:

Pictures Show :

Ruby Nozzle
