Metal Processing Ruby Nozzle Coil Winding High Corrosion Resistance

Ruby is the hardest among the materials selected for

coil winding nozzle entrance and exit.

Their single crystal (mono crystalline) structure allows

diamond polishing to a mirror finish unmatched by other material,reducing friction and protecting the wire.Shown at left is a photomicrograph of a ruby exit orifice.

Issues with Ruby Tipped Nozzle

The body of a ruby tipped nozzle is usually made of a stainless steel tube that retains the longitudinal grains inherent to all hard drawn steel tubes, which will form a bulge in the bore when bent then straightened. Upon impact, the ruby tip either will be broken or fractured which may not be visible to the naked eyes but which nevertheless will damage the wire. Therefore, a ruby nozzle after impact should be discarded.

Product Features

The product is made of stainless steel and ruby by precise processing and combination.

The rigidity of ruby is above than the level 9 and is just less than that of diamond.

It is a single crystal and can be made with high brightness and cleanness. It can effectively protect paint film and long-term contiual work to ensure the high insulation of wire

coil suffers no hurt.

Product Advantages

1. High toughness,low friction coefficient of ruby, high corrosion resistance.

2. Longer service life and fine performance.

3.The most economical prices.

Products description:

Ruby Nozzle Drawings

Size List:

Above table for reference, can be customized according to customer requirements.

Pictures Show :

Ruby Nozzle

Ruby Nozzle Inner package
